4 Antennas Network Extender

Name: 4 Antennas Network Extender
SKU: 33059029344
Availability: InStock

Price range: £21.00 through £27.00

Bundle

Color

Clear

SKU: 33059029344 Category: Tech & Electronics

Description

FAQ:

The Xiaomi router Support IPTV,L2TP and PPPOE?

No, don’t Support.

Note：The xiaomi router 4A is Chinese version ，we suggest you download mi router to set the router if you can’t understanding Chinese manual.

Xiaomi Router 4A gigabit version has dual CPU, Gigabit network access and 4 high-gain antennas. 128MB large storage and 1167Mbps ensures high performance. Smart APP control can effectively prevent wifi-squatter. It is absolutely a superb choice for you.

Features:

Dual Core CPU for Faster Network Speed

Featuring dual core four threading CPU, the single core frequency can reach to 880MHz. Strong performance easily support gigabit network and dual band WiFi data transmission.

Wireless Dual Band

Support 2.4GHz and 5GHz two frequency bands. The max speed rate can reach to 1167Mbps. 2.4GHz band supports longer, better coverage and through-wall performance. 5GHz band uses 802.11ac technology. Less interference, high rate. Watch HD video and play smooth game.

Dual Band Shares One WiFi Name

Xiaomi router 4A support dual band. It combines 2.4GHz and 5GHz in one WiFi name. 2.4GHz has better through-wall performance and 5GHz has higher rate.

High Gain 4 Antennas for Stronger Signal

4 external high-gain omnidirectional antennas. Hugely improves transmission performance and do great job under various complex environment.

128MB Large Memory

Smart home appliance era. More devices need stable connection. Xiaomi router 4A adopts 128MB memory that ensures stable transmission.

Smart Error Correction Calculation

5GHz frequency support LDCP error correction calculation. Strengthen anti-interference performance. Boost WiFi signal and improve transmission speed rate

Package list:

1 * Router

1 * Power Adapter(Original US plug)

1 * User Manual(in chinese)

Xiaomi Mi Router 4A Gigabit Edition 100M 2.4GHz 5GHz High Gain 4 Antennas Remote APP Control

Hardware
Brand	Xiaomi
CPU	MT7621A
RAM	64 MB128MB DDR3
ROM	16MB
2.4G WiFi	2X2 (support IEEE 802.11N, 300Mbps max)
5G WiFi	2X2 (support IEEE 802.11AC, 867Mbps max)
Antenna	4 PCS
Heat dissipating system	Natural heat dissipation
Material	ABS
Interfaces
Lan port	2 (10/100 Auto MDI/MDIX)
WAN port	1 (10/100 Auto MDI/MDIX)
LED indicators	3 (Red/Blue/Yellow)
Button	1 x Reset button
DC input	1
Antenna
Dual bands	2.4GHz / 5GHz
Wireless channels	2.4GHz Channel: 1,2,3,4,5,6,7,8,9,10,11,12,13
Wireless channels	5GHz Channel: 36,40,44,48,52,56,60,64,149,153,157,161,165
Modulation mode	11b: DSSS: DBPSK(1Mbps),DQPSK(2Mbps),
	CCK(5.5/11Mbps)
	11a/g: OFDM:BPSK(6/9Mbps),
	QPSK(12/18Mbps),16QAM(24/36Mbps),
	64QAM(48/54Mbps)
	11n: MIMO-OFDM:BPSK,QPSK,16QAM,64QAM.
	Rate: MCS0~MCS15
	11ac: MIMO-OFDM:BPSK,
	QPSK,16QAM,64QAM,256QAM
	Rate: MCS0~MCS9
Receiving sensitivity	11Mbps:≤-90dBm,54 Mbps:≤-72dBm,
	HT20 MCS7:≤-69dBm,
	HT40 MCS7:≤-66dBm,
	VHT20 MCS8:≤-65dBm,
	VHT40 MCS9:≤-60dBm,
	VHT80 MCS9:≤-58 dBm
Software
Operating system	MiWiFi ROM (Supports Web, Android, iOS)
Wireless security	WPA-PSK/WPA-PSK2 encryption, Wireless access control (black and white list), SSID hiding
Protocol standards	IEEE 802.11a/b/g/n/ac, IEEE 802.3/3u
Approval standards	GB9254-2008 YD/T993-1998 GB4943.1-2011
Working environment	Operating temperature: 0-40°C
	Working humidity: 10%-90%RH
	Storage temperature : -40-70°C
	Storage humidity: 5%-90%RH
	Power: 12W max

Additional information

Brand Name	Xiaomi
Origin	CN(Origin)
With Modem Function	No
Type	Wireless
Wired Transfer Rate	1000Mbps
WAN Ports	1 x10/100/1000Mbps
Wi-Fi Supported Frequency	2.4G & 5G
5G Wi-Fi Transmission Rate	867Mbps
Package	Yes
Supports WDS	No
Max. LAN Data Rate	300Mbps
Model Number	Xiaomi router 4A
Standards And Protocols	Wi-Fi 802.11g
2.4G Wi-Fi Transmission Rate	300 Mbps
LAN Ports	2
Supports WPS	No
Function	QoS
